12.9. Email notifications

User shall have ROLE_ADMIN to manage Email notifications.

Change the email notification

  1. Navigate to the Settings tab.
  2. Select the Email notifications section.
  3. Choose any of the email notification types (e.g. LONG_INIT) on the left:
    CP_EmailNotification
  4. Remove Keep admins informed and Keep owners informed options. This email notification type will no longer inform admins and owners.
    CP_EmailNotification
  5. Add a new user to the Informed users. While typing system will suggest you users. When you selected all users, click outside this field.
    CP_EmailNotification
  6. Change the Threshold parameter to e.g. 1400.
    CP_EmailNotification
  7. Press the Save button to save all changes to the LONG_INIT email notification template.
    CP_EmailNotification

Configure automatic email notifications on users' runs

Here, the mechanism of automatic email notifications for IDLE, HIGH-CONSUMED and HIGH-CONSUMED NETWORK BANDWIDTH runs is described.

IDLE runs

The system behavior for the IDLE runs is defined by the set of the following parameters:

Setting Preference-duplicate Description
Max duration of idle (min) system.max.idle.timeout.minutes Specifies the duration in minutes after that the system should check node's activity.
If after this duration node's CPU utilization will be below CPU idle threshold - email notification IDLE_RUN will be sent to the user,
and the run itself will be marked by CP_EmailNotification label
Action delay (min) system.idle.action.timeout.minutes Specifies the duration in minutes.
If node's CPU utilization is still below CPU idle threshold for this duration after the Max duration of idle is over -
an action, specified in Action field will be performed
CPU idle threshold (%) system.idle.cpu.threshold Specifies percentage of the node's CPU utilization, below which an Action shall be taken
Action system.idle.action Sets which action to perform with the node, that has the CPU utilization below than CPU idle threshold:
  • NOTIFY - only send email notification IDLE_RUN.
    This action will be repeated every Resend delay if the node's CPU utilization will be still below than CPU idle threshold
  • PAUSE - pause an instance if possible (only if the instance is On-Demand, Spot instances are skipped) and send single email notification IDLE_RUN_PAUSED
  • PAUSE_OR_STOP - pause an instance if it is On-Demand or stop an instance if it is Spot,
    and send the corresponding email notification IDLE_RUN_PAUSED / IDLE_RUN_STOPPED
  • STOP - Stop an instance, disregarding price-type, and send single email notification IDLE_RUN_STOPPED
Resend delay (sec)
Only for IDLE_RUN notification		 Specifies the duration in seconds.
Defines a delay after which the IDLE_RUN notification will be sent repeatedly in case when node's CPU utilization is still below CPU idle threshold.
IDLE_RUN notifications will be repeated until Action delay is over. Then Action will be performed.
Note: if Action is set as NOTIFY - sending notifications will be continued every Resend delay.

Default value: -1. In that case, IDLE_RUN notifications will not be resending.
system.resource.monitoring.period Specifies period (in milliseconds) between the scannings of running instances to collect the monitoring metrics.
After each such period, it's defined to display CP_EmailNotification label for the specific instance or not

Described parameters are configured in "common" panel for all IDLE notifications - IDLE_RUN, IDLE_RUN_PAUSED, IDLE_RUN_STOP, e.g.:
CP_EmailNotification

Saving of the changes in described parameters values at the EMAIL NOTIFICATIONS form automatically changes the corresponding values in PREFERENCES, and vice versa.

Notifications for long paused runs

There are two notification types for the runs that are in the PAUSED state for a long time:

LONG_PAUSED - this notification will be sent if the run has been paused for a long time.
LONG_PAUSED_STOPPED - this notification will be sent if the run has been paused for a long time and should be terminated.

The system behavior for the "long paused" runs is defined by the set of the following parameters:

Setting Preference-duplicate Description
Action
Common setting for both notification types		 system.long.paused.action Sets which action to perform with the node, that has been paused for a long time:
  • NOTIFY - only send email notification LONG_PAUSED. Then this action will be repeated every Resend delay if the run will be still paused
  • STOP - terminate the paused run and send single email notification LONG_PAUSED_STOPPED
Threshold (sec)
Separately sets for each notification type		 Specifies the duration in seconds.
Defines the delay after which an action, specified in Action field, will be performed and the corresponding notification will be sent if the run is still paused.
Resend delay (sec)
Only for LONG_PAUSED notification type		 Specifies the duration in seconds.
Defines a delay after which the LONG_PAUSED notification will be sent repeatedly in case when the run is still paused after a Threshold duration.
Note: if Action is set as NOTIFY - sending notifications will be continued every Resend delay.

Default value: -1. In that case, LONG_PAUSED notifications will not be resending.

Saving of the changes in described parameter value (for Action) at the EMAIL NOTIFICATIONS form automatically changes the corresponding value in PREFERENCES, and vice versa.
For usage of such preferences see in the section here.

For example, LONG_PAUSED notification settings:
CP_EmailNotification

Example of the scenario for automatic notifications for "idle" runs

In general, the system behavior is the following:

  1. User launches a run
  2. After Max duration of idle (system.max.idle.timeout.minutes) period, the system starts to check the node's activity. Then, the state of the node is checked every system.resource.monitoring.period
  3. If the node's CPU utilization becomes below the CPU idle threshold (system.idle.cpu.threshold):
    • email notification IDLE_RUN is being sent, the run itself is being marked by the CP_EmailNotification label
  4. IDLE_RUN notification is being repeated every Resend delay (configured for IDLE_RUN) until the Action delay (system.idle.action.timeout.minutes) period is over.
  5. After Action delay (system.idle.action.timeout.minutes), if the node's CPU utilization is still below CPU idle threshold (system.idle.cpu.threshold):
    • email notification IDLE_RUN is being sent (in case when Action (system.idle.action) is set as NOTIFY)
    • run is being paused/stopped and the corresponding email notification IDLE_RUN_PAUSED or IDLE_RUN_STOPPED is being sent (in case when Action (system.idle.action) is set as PAUSE / PAUSE_OR_STOP / STOP)
  6. In case when Action (system.idle.action) is set as NOTIFY, email notifications IDLE_RUN continue to be sent every Resend delay, if the node's CPU utilization remains below the CPU idle threshold (system.idle.cpu.threshold).
  7. In case when run has been paused:
    • if the Action (for Long Paused notifications - system.long.paused.action) is set as NOTIFY, and the run has been paused for a Threshold period (configured for LONG_PAUSED), the notification LONG_PAUSED is being sent.
      • and if Resend delay (for LONG_PAUSED) is configured, then email notifications LONG_PAUSED continue to be sent every Resend delay, if the run is still paused
    • if the Action (for Long Paused notifications - system.long.paused.action) is set as STOP, and the run has been paused for a Threshold period (configured for LONG_PAUSED_STOPPED), run is being stopped (terminated) and the corresponding email notification LONG_PAUSED_STOPPED is being sent.

Note: users can manually disable the automatic pausing of on-demand instances if they aren't used. For that the "Auto pause" checkbox at the Launch page shall be unchecked before the run:
CP_EmailNotification
This action cancels only the auto pause, but the RUN_IDLE email notifications will be being sent (if the corresponding conditions will be met).

HIGH-CONSUMED runs

All settings that configure actions/notifications for "high-consumed" runs are placed in the EMAIL NOTIFICATIONS section. These settings duplicate some System Preferences and also can be configured from the PREFERENCES section, but it is more comfortable to configure them from the NOTIFICATIONS.

HIGH_CONSUMED_RESOURCES notification settings:
CP_EmailNotification

The system behavior for the "high-consumed" runs is defined by the set of the following System-level parameters (Preferences):

Setting Preference name Description
Threshold of disk consumption (%) system.disk.consume.threshold Specifies the node's disk threshold (in %) above which the email notification HIGH_CONSUMED_RESOURCES will be sent,
and the corresponding run will be marked by CP_EmailNotification label
Threshold of memory consumption (%) system.memory.consume.threshold Specifies the node's memory threshold (in %) above which the email notification HIGH_CONSUMED_RESOURCES will be sent,
and the corresponding run will be marked by the CP_EmailNotification label
system.monitoring.time.range Specifies the threshold timeout (if a real average resource consumption is higher then any of the thresholds above for that timeout,
a notification shall be sent). Also defines the period after which the notification will be sent again, if the problem is still in place

So, when memory or disk consuming will be higher than a threshold value for a specified period of time (in average) - a notification will be sent (and resent after a delay, if the problem is still in place).

Saving of the changes in described parameters values at the EMAIL NOTIFICATIONS form automatically changes the corresponding values in PREFERENCES, and vice versa.
For usage of such preferences see in the section here.

HIGH-CONSUMED NETWORK BANDWIDTH runs

All settings that configure actions/notifications for "high-consumed network bandwidth" runs are placed in the EMAIL NOTIFICATIONS section.
These settings duplicate some System Preferences and also can be configured from the PREFERENCES section, but it is more comfortable to configure them from the NOTIFICATIONS.

HIGH_CONSUMED_NETWORK_BANDWIDTH notification settings:
CP_EmailNotification

The system behavior for the HIGH-CONSUMED NETWORK BANDWIDTH runs is defined by the set of the following parameters:

Setting Preference-duplicate Description
Network bandwidth limit (bytes/sec) system.pod.bandwidth.limit Defines the network bandwidth threshold (in bytes/sec). Default value is 0 - this means there is no threshold.
Network bandwidth
measurement period (min)		 system.max.pod.bandwidth.minutes Specifies the duration in minutes after which the system will check pod's network consuming in case when Network bandwidth limit > 0.
If after this duration pod's network consuming is still higher than Network bandwidth limit:
  • email notification HIGH_CONSUMED_NETWORK_BANDWIDTH will be sent to the user
  • the run itself will be marked by the CP_EmailNotification label.
Action delay (min) system.pod.bandwidth.action.backoff.period Specifies the duration in minutes.
If pod's network consuming is higher than Network bandwidth limit for this duration of time after the Network bandwidth measurement period,
then an action specified in Action field will be performed.
Action system.pod.bandwidth.action Sets which action to perform with the pod, that has the network consuming higher than Network bandwidth limit.
Currently, possible actions:
  • NOTIFY - sends the email notification HIGH_CONSUMED_NETWORK_BANDWIDTH.
    This action will be repeated every Action delay if the network consuming will be still higher than Network bandwidth limit
  • LIMIT_BANDWIDTH (not applicable yet) - restricts pod's bandwidth
system.pod.bandwidth.monitor.delay Specifies period (in milliseconds) between the scannings of running pods to collect the monitoring metrics.
After each such period, it's defined to display CP_EmailNotification label for the specific instance or not

So, when network consumption will be higher than a threshold value for a specified period of time (in average) - a notification will be sent (and resent after a delay, if the problem is still in place).

Saving of the changes in described parameters values at the EMAIL NOTIFICATIONS form automatically changes the corresponding values in the PREFERENCES, and vice versa.
For usage of such preferences see in the section here.

Push notifications

All email notifications, that are sending by Cloud Pipeline platform, are also duplicated as push notifications. This allows to view notifications right in the platform GUI.
Push notifications do not require additional configuring - they are fully the same as corresponding email notifications, i.e. have the same header, content, recipients list, frequency and trigger of sending, etc.
Therefore, administrator shall only configure email notifications once - platform will automatically duplicate emails sending as push notifications on the GUI.

View push notifications

Once any system event is occurred and its trigger for sending email notification has fired, email will be sent to the configured recipients (according to the notification template settings).
Simultaneously, the push notification (with the same subject and body as in the email) will be "sent" to the same recipients.
If these recipients are working in the Cloud Pipeline GUI at that moment or when they will open the platform GUI next time, they will view the corresponding push notification - in the right-upper corner, over any layout Cloud Pipeline page, e.g.:
CP_EmailNotification

At the same moment, near the Notifications icon in the main menu will appear a count of new unread messages:
CP_EmailNotification

To view details and full notification body, click the notification tile. Notification will be opened in a pop-up:
CP_EmailNotification
Once that pop-up is closed, the notification will be marked as "read", the counter near the Notifications icon in the main menu will decrease.
If you close the push notification by click the cross-button on it, such notification also will be marked as "read":
CP_EmailNotification

If there are several push notifications were received, a couple of them will be shown with short details and the rest will be collapsed into a tile, e.g.:
CP_EmailNotification

Such collapsed tile contains:

  • a label with a count of collapsed notifications
  • button hide - to hide all appeared push notifications but left them "unread"
  • button read all - to hide all appeared push notifications and mark them as "read"

Notifications section

Notifications section allows to view all push notifications/emails sent to the current user.
To open the section, click the corresponding button in the main menu:
CP_EmailNotification

This page allows to view notifications. By default, new "unread" notifications list will be shown (as on the picture above).
To view "read" notifications list, select the corresponding item in the dropdown list near the page title:
CP_EmailNotification
"Read" notifications list will appear:
CP_EmailNotification

Notifications list has the following fields:

  • Status - status of the notification ("unread" or "read", distinct by the icon color)
  • Title - notification title - it corresponds to the original email subject
  • Text - first row of the notification text - it corresponds to the beginning of the original email body
  • Created date - date and time of the notification push
  • Read date - date and time when the notification is read

Additionally, the page contains controls:

  • Read all button - to mark all new "unread" notifications as "read"
  • Refresh button - to refresh notifications lists and update a counter of "unread" notifications

To view the notification - click it in the list, e.g.:
CP_EmailNotification
Notification will be opened in a pop-up:
CP_EmailNotification
If the notification was new and "unread" - once that pop-up is closed, the notification will be marked as "read" and will be placed to the corresponding notifications list.

Settings

Mute notifications

If user do not want to receive push notifications over all forms and pages in the platform GUI - they can be "muted".
For that, user shall:

  1. Open System settings
  2. Select the tab My profile
  3. In the Profile sub-tab, tick the checkbox "Mute email notifications":
    CP_EmailNotification

After, new notifications will be appearing only in the Notifications section, but corresponding pushs will not be showing.

Storing period

Admins can configure the period for which described GUI notifications will be stored.
It can be done via the system preference system.notifications.exp.period.
This preference set the duration of the period in days after which old received notifications will be removed.
The default value is not set (blank). This means that notifications are not being removed at all.
